FULLY PROGRAMMABLE

• Powerful AI processor with dedicated 16 core CPU + GPU
 (384Core, 1.5TFLOPS)
• Available with 3 NVIDIA Jeston processing units (2 Nanos +1 NX or 3 NXs), the Go1 is ready to be tapped into using the ROS open-source robotics suite.
• Using Python, users can dive into all the complex problems the Go1 is ready to solve. Great for exploring the innovation of robotic quadrupeds.

  GO1 EDU CAPABILITIES

 SUPER SENSORAY SYSTEM

The SS System gives the Go1 a full view coverage with 5 sets of fish-eye stereo depth cameras and AI post-processing. Each camera has a veiwing angle of around 150°x170°.

BUILT-IN SUPER AI HASH RATE

The Go1 is powered by a 16 core CPU  and a 384 core GPU
 with 1.5 TFLOPS. This powerful cobintaion allowes for complex AI processes such as human and object detection.

 STRONG & RELIABLE POWER SYSTEM

The Go1 is equiped with the new patented ulta-lightweight, low-noise and long life power joints.

• Joint Motor Body/thigh joints: C1-8: 520 g 23.70 N.m
• Knee joint: C1-8×1.5 ratio 35.55 N.m
• A patented heat pipe-assisted heat dissipation system built into the vicinity of the knee joint motor.

 INTELLIGENT SIDE-FOLLOWING SYSTEM

Using the patented Wireless Vector Positioning And Control Technology :

• Allows the Go 1 to easily follow someone and remain at their side
• No need to worry about the robot since it's right beside you
• Capable of helping robot choosing better route in complex environment

The Go1 Variants at a Glance

  GO1 AIR

The lightweight and compact Go1 Air is the entry-level model in the Go1 series by Unitree Robotics. The standard Go1 Air has 1 processor and 1 Super Sensory System.

  GO1 EDU (2D LIDAR SYSTEM)

The Go1 Edu comes equiped with SLAMTEC 2D LiDAR. This system offers lots of development possibilities. It’s aimed in particular at higher education and professionals, for developing applications in fields ranging from service robotics to autonomous surveillance.

• High-precision indoor mapping.
• Large outdoor environment mapping with SLAMTEC third-generation high-performance SLAM graph optimization and SharpEdge™ mapping technology.
• Complete with a cross-platform SDK that allows for coherent ROS environment integration.
• Integrates map building, localization, and navigation in real-time.
• Utilizes a high-performance SLAM engine and laser range scanner

  GO1 EDU PLUS (3D LIDAR SYSTEM)

The Go1 Edu Plus is equiped with the 16 channel Robosense 3D LiDAR is ideal for environment mapping, autonomous driving, and UAV mapping. This system provides reliable data for localization, navigation and obstacle avoidance.

• Comes with Robosense RS-LiDAR-16, this is a 16-beam miniature LiDAR with 150m range and 2cm accuracy.

• Ideal for environment mapping, autonomous driving, and UAV mapping.
• Compact housing of the RS-LiDAR-16, mounted with 16 laser/detector pairs, rapidly spins and sends out high-frequency laser pulses to continuously scan the surrounding environment, collecting real-time 3D point clouds with reflectivity of objects to enable machines to “see.”
•

Provides reliable data for localization, navigation and obstacle avoidance.
